Biometric Security
BOOM BARRIER GATE FACTORY manufactures biometric access control systems, including face recognition terminals and electric magnetic doors. The face recognition system uses an Rv1109 AI chip with 0.5-2M recognition distance and under 300ms recognition time, supporting remote, swipe, and password card recognition, with a touch screen and outdoor waterproof design.
What is an access control system?
Face recognition <300ms + magnetic door locks. 30,000 face database capacity with multi-factor authentication support.
Model #1
Face Recognition Terminal
| Electric magnetic door G01/G02 parameter specifications | |
| Chassis material | 201 stainless steel, automotive baking paint |
| Cabinet dimensions | 1830(H)x180(L)x1800(W)mm (widest) |
| Passage clear width | 850~1450mm |
| Ambient humidity | ≤95% (no condensation) |
| Operating voltage | AC220V±10% 50/60Hz |
| Operating temperature | -30℃ to +75℃ |
| Louver door width | 1200~1800mm (adjustable) |
| Total power consumption | < 60W |
| Motor specification | DC brushless motor |
| Remote control distance | 30M |
| Communication interface | 1/0 switch signal |
| Protection grade | IP54 |
| Standard color | matte gray |
| --- | |
| Face recognition system F01/F02 parameter specifications | |
| Specifications 246mm (length) x 129mm (width) x 23mm (thickness) | |
| Resolution 1024x600 FHD screen | |
| Processor Rv1109 dedicated AI chip, 2 cores 1.5 GHZ | |
| The recognition distance is 0.5-2M, and the recognition time is less than 300ms | |
| Binocular camera 300W pixel wide dynamic, adaptive to various complex scenes | |
| Device power consumption 15W | |
| Operating voltage DC12V ± 10% | |
| Card recognition supports remote/swipe/password | |
| Touch screen/outdoor waterproof | |
